GT 24 -  Formwork Girder
GT 24 -  Formwork Girder
GT 24 -  Formwork Girder
#

GT 24 - Formwork Girder

The versatile lattice girder with a high load-bearing capacity is used for column and other formwork systems. The girder nodes with mini-dovetail joi... See more

The versatile lattice girder with a high load-bearing capacity is used for column and other formwork systems.

The girder nodes with mini-dovetail jointing guarantee the durability of the GT 24 Lattice Girder. The struts penetrate the chords along the whole cross-section and there are practically no cavities which could collect and hold moisture

The Certificate of Conformity confirms that GT 24 Formwork Girder corresponds to the technical rules of DIN EN 13377.

GT 24 Formwork Girders are frequently used for climbing systems for working at height – with crane-movable platforms as well as hydraulically operated self-climbing systems.

See less

Delivery time: 3-5 working days
  • Universal wooden formwork girder with a 24 cm overall height for wall, column and slab formwork systems.

  • Standard lengths from 0.90 m to 6.00 m in 30 cm increments; extralong lengths up to 17.85 m on request

  • Weight: 5.9 kg/m

  • Permissible bearing force: 28.00 kN (at the nodes)

  • Permissible bending moment: 7.00 kNm

  • Bending stiffness: EIy = 887 kNm²; Iy = 8.064 cm4
