GT 24 - Formwork Girder
- category: სამშენებლო კოჭი
- Brands: PERI
The versatile lattice girder with a high load-bearing capacity is used for column and other formwork systems. The girder nodes with mini-dovetail joi... See more
The versatile lattice girder with a high load-bearing capacity is used for column and other formwork systems.
The girder nodes with mini-dovetail jointing guarantee the durability of the GT 24 Lattice Girder. The struts penetrate the chords along the whole cross-section and there are practically no cavities which could collect and hold moisture
The Certificate of Conformity confirms that GT 24 Formwork Girder corresponds to the technical rules of DIN EN 13377.
GT 24 Formwork Girders are frequently used for climbing systems for working at height – with crane-movable platforms as well as hydraulically operated self-climbing systems.
See less
-
Universal wooden formwork girder with a 24 cm overall height for wall, column and slab formwork systems.
-
Standard lengths from 0.90 m to 6.00 m in 30 cm increments; extralong lengths up to 17.85 m on request
-
Weight: 5.9 kg/m
-
Permissible bearing force: 28.00 kN (at the nodes)
-
Permissible bending moment: 7.00 kNm
-
Bending stiffness: EIy = 887 kNm²; Iy = 8.064 cm4
Products offered
delivery
- When purchasing products for up to 100 GEL, the delivery price is 6 GEL;
- When purchasing products in the amount of 100 to 500 GEL, the delivery price is determined on the basis of: 1 km - 1.50 GEL;
- When purchasing products worth more than GEL 300, delivery is free (Tbilisi);
- The cost of delivery outside the city is determined at the rate: 1 km - 2 GEL.
Delivery time:
- Tbilisi | Rustavi | Mtskheta | Kutaisi | Batumi
Delivery time: 3-5 working days
- Out of town:
Delivery time: 4-5 working days
Note: Delivery is carried out only to the address, without unloading from the car and delivery to the apartment.
Product comparison
GT 24 - Formwork Girder
choose a product
- ხის კოჭი 2.9 მ
- Wooden Beam 3.6 m (PERI)
- Wooden Beam 3.3 მ (FORM-ON)
- Wooden Beam 2.45 m ( PERI ) VT -20
- Wooden Beam 3.9 m PF20 (PFEIFER)
- Wooden Beam 5.9 m ( PERI ) VT -20
- Wooden Beam 4.9 m (PERI) VT-20
- Wooden Beam 5.9 მ (FORM-ON)
- Wooden Beam 2.9 m (PERI) VT-20
- Wooden Beam 3.9m ( PERI ) VT -20
- Wooden Beam 5 M
- Wooden Beam 3.6 მ (EKO)
- Wooden Beam 3.6 M
- Wooden Beam 1.45 m (PERI) VT-20
- Wooden Beam 5.9 M
-
Universal wooden formwork girder with a 24 cm overall height for wall, column and slab formwork systems.
-
Standard lengths from 0.90 m to 6.00 m in 30 cm increments; extralong lengths up to 17.85 m on request
-
Weight: 5.9 kg/m
-
Permissible bearing force: 28.00 kN (at the nodes)
-
Permissible bending moment: 7.00 kNm
-
Bending stiffness: EIy = 887 kNm²; Iy = 8.064 cm4
